Goladstar is at the forefront of manufacturing advanced solar PV modules or solar panels that enable our customers to meet their energy requirements sustainably and efficiently.
We design, engineer and manufacture high-quality solar PV modules that are built to last, delivering maximum efficiency and long-term performance.
Our state-of-the-art manufacturing facilities with the latest European 12 BB automated line and cutting-edge technology ensure that our products meet the highest standards of quality and durability. With years of experience in the solar industry, we are dedicated to providing our customers with the best possible products and services.
We offer a range of different solar PV module options to suit different needs and applications, and our expert team is available to help you choose the best solution for your specific needs. Whether you’re looking to power your home, business, or community, we have the expertise and resources to help you achieve your goals.
| Module Type | 325W | 330W | 335W | 340W |
|---|---|---|---|---|
| Capacity Rating – Pm x (Wp) | 325 | 330 | 335 | 340 |
| Maximum Operating Current (Imp) | 8.87 | 8.99 | 9.13 | 9.17 |
| Maximum Operating Voltage (Vmp) | 36.65 | 36.72 | 36.70 | 37.10 |
| Short Circuit Current (Isc) | 9.17 | 9.23 | 9.50 | 9.63 |
| Open Circuit Voltage (Voc) | 45.50 | 45.57 | 45.80 | 46.15 |
| Module Size | 1985 x 1000 x 35 / 1985 x 1000 x 40.5 | |||
| Weight Approx | 21 KG / 22.310 KG | |||
| Module Type | 360W | 370W | 380W | 390W | 400W |
|---|---|---|---|---|---|
| Capacity Rating – Pmax (Wp) | 360 | 370 | 380 | 390 | 400 |
| Maximum Operating Current (Imp) | 9.13 | 9.27 | 9.51 | 9.57 | 9.64 |
| Maximum Operating Voltage (Vmp) | 39.50 | 39.94 | 40.03 | 40.74 | 41.50 |
| Short Circuit Current (Isc) | 9.67 | 9.79 | 10.08 | 10.05 | 10.23 |
| Open Circuit Voltage (Voc) | 48.52 | 49.12 | 49.72 | 49.87 | 49.90 |
| Module Size | 1985 x 1000 x 35 / 1985 x 1000 x 40.5 | ||||
| Weight Approx | 21 KG / 22.35 KG | ||||
| Module Type | 400W | 410W | 420W | 430W | 440W |
|---|---|---|---|---|---|
| Capacity Rating – Pmax (Wp) | 400 | 410 | 420 | 430 | 440 |
| Maximum Operating Current (Imp) | 10.2 | 10.23 | 10.37 | 10.43 | 10.49 |
| Maximum Operating Voltage (Vmp) | 40.02 | 40.16 | 40.42 | 41.14 | 41.96 |
| Short Circuit Current (Isc) | 10.62 | 10.64 | 10.95 | 11.03 | 11.07 |
| Open Circuit Voltage (Voc) | 47.85 | 47.99 | 48.25 | 48.74 | 48.96 |
| Module Size | 2115 x 1050 x 35 / 2115 x 1050 x 40.5 | ||||
| Weight Approx | 24 KG / 25 KG | ||||
| Module Type | 360W | 370W | 380W | 390W | 400W |
|---|---|---|---|---|---|
| Capacity Rating – Pmax (Wp) | 360 | 370 | 380 | 390 | 400 |
| Maximum Operating Current (Imp) | 9.13 | 9.27 | 9.51 | 9.57 | 9.64 |
| Maximum Operating Voltage (Vmp) | 39.50 | 39.94 | 40.03 | 40.74 | 41.50 |
| Short Circuit Current (Isc) | 9.67 | 9.79 | 10.08 | 10.05 | 10.23 |
| Open Circuit Voltage (Voc) | 48.52 | 49.12 | 49.72 | 49.87 | 49.90 |
| Module Size | 1985 x 1000 x 35 / 1985 x 1000 x 40.5 | ||||
| Weight Approx | 21 KG / 22.35 KG | ||||
| Module Type | 520W | 525W | 530W | 535W | 540W | 545W |
|---|---|---|---|---|---|---|
| Capacity Rating – Pm x (Wp) | 520 | 525 | 530 | 535 | 540 | 545 |
| Maximum Operating Current (Imp) | 12.53 | 12.58 | 12.63 | 12.68 | 12.76 | 12.93 |
| Maximum Operating Voltage (Vmp) | 41.55 | 41.73 | 41.96 | 42.19 | 42.35 | 42.16 |
| Short Circuit Current (Isc) | 13.39 | 13.40 | 13.43 | 13.46 | 13.63 | 13.73 |
| Open Circuit Voltage (Voc) | 48.02 | 48.12 | 48.16 | 48.60 | 48.74 | 48.96 |
| Module Size (mm) | *2283 x 1134 x 35 / **2283 x 1134 x 40.5 | |||||
| Weight Approx | *28.1 KG (Without Central Support) / **28.9 KG (With Central Support) | |||||
| Module Type | 625W | 630W | 635W | 640W | 645W | 650W |
|---|---|---|---|---|---|---|
| Capacity Rating – Pm x (Wp) | 625 | 630 | 635 | 640 | 645 | 650 |
| Maximum Operating Current (Imp) | 17.13 | 17.19 | 17.25 | 17.31 | 17.37 | 17.44 |
| Maximum Operating Voltage (Vmp) | 36.49 | 36.66 | 36.82 | 37.01 | 37.15 | 37.32 |
| Short Circuit Current (Isc) | 18.51 | 18.57 | 18.63 | 18.69 | 18.75 | 18.85 |
| Open Circuit Voltage (Voc) | 42.66 | 42.87 | 43.08 | 43.28 | 43.47 | 43.66 |
| Module Size (mm) | 2435 x 1310 x 35 / 2435 x 1310 x 40.5 | |||||
| Weight Approx | 27.5 KG / 28.5 KG | |||||
From mobility to solar energy, we’re here to help you move forward with confidence.
